Description

Dimensions of the product (mm):
315x900x295
Width:
900 mm
Depth (mm):
295 mm
Product Height (mm):
315 mm
Net weight (kg):
20.300 kg
Gross weight (kg):
25.000 kg
Packed width:
1000 mm
Packaged depth:
460 mm
Height (mm) packed:
405 mm
Dimensions of the packed product (mm):
405X1000X460
Maximum stackability:
5
Type of packaging:
Cardboard
Packaging composition – paper & cardboard (kg):
3.970 kg
Packaging composition – polystyrene (kg):
0.000 kg
Packaging composition – wood (kg):
0.000 kg
Packaging composition – plastic (kg):
0.419 kg Stainless steel Integrated hood Type
Product family:
Hood
Hood Type:
Integrated hood
Hood width:
90 cm
Extraction:
Extraction
Electronic control:
Yes
EAN code:
8017709253851
Aesthetics
Colour:
Stainless steel
Finishing:
Satin
Aesthetic:
Universale
Design:
Fully integrated
Material:
Stainless steel
Type of steel:
Brushed
Programs / Functions
Intensive/turbo setting: when extra fast extraction is required. Switch off automatically: A special setting, to run after the end of cooking for a pre-set time and then switch off automatically.
No. of speeds:
3
Intensive speed:
Yes
Time-setting options:
Automatic switch-off
Controls
Control setting:
Electronic buttons
Led color:
White
Technical Features
Filters: Model has filters to help remove grease from the steam emanating from the pans during cooking. Lights: All cooker hoods feature lights to illuminate the cooking area or add to the ambience of the kitchen. Warning light(s): to advise when filters need changing.
No. of lights:
4
Light type:
LED
Light Power:
1 W
Light color temperature scale (°K):
3000 °K
Free outlet maximum capacity:
1400 m³/h
Motor power:
550 W
No. of filters:
2
Anti-grease filters:
Buffle
Filter replacement indicator:
Yes
Minimum distance from GAS hob:
650 mm
Minimum distance from ELECTRIC hob:
750 mm
Vent outlet:
150 mm
Non return valve:
Yes
Electrical Connection
Electrical connection rating:
555 W
Voltage:
220-240 V
Frequency (Hz):
50-60 Hz
Power supply cable length:
1500 mm
Speed 1
Extraction rate IEC 61591:
552 m³/h
Noise level IEC 60704-2-13:
46 dBA
Power:
154 W
Speed 2
Extraction rate IEC 61591:
950 m³/h
Noise level IEC 60704-2-13:
63 dBA
Power:
255 W
Speed 3
Extraction rate IEC 61591:
1412 m³/h
Noise level IEC 60704-2-13:
71 dBA
Power:
334 W
Intensive speed
Extraction rate (IEC 61591):
1555 m³/h
Noise level IEC 60704-2-13:
74 dBA
Power:
370 W
