The stainless-steel gas hob with
FlameSelect: achieve perfect cooking
results thanks to nine precisely defined
power levels.
● FlameSelect: for a precise adjustment of the flame in nine
defined levels.
● Continuous steel pan support: for high stability of cookware.
● Sword knobs: for an ergonomic control.
● Surface colour: Stainless steel

PCP6A5B90Z
60 cm, Gas hob with integrated controls,
Stainless steel
The stainless-steel gas hob with
FlameSelect: achieve perfect cooking
results thanks to nine precisely defined
power levels.
Design
– Stainless steel
Comfort:
– FlameSelect
– Sword control knobs
– 1 Hand ignition
– Cast iron continuous pan supports
Power and size:
– 4 Gas burners
– 1 rapid, 2 standard, 1 economy burner
– Left rear: Standard burner up to 1.75 KW
– Right rear: Rapid burner up to 3 KW
– Left front: Standard burner up to 1.75 KW
– Right front: Economy burner up to 1 KW
Environment+safety:
– Flame failure safety device
– Preset nozzle: Liquid gas (28-30/37mbar)
Measurements:
– Power cord lenght 1m
Accessories
– Natural gas nozzles (20 mbar) included

Technical Data
Product name/family : gas hob w integrated controls
Construction type : Built-in
Energy input : Gas
Total number of positions that can be used at the same time : 4
Required niche size for installation (HxWxD) :
45 x 560-562 x 480-492
Width of the product (mm) : 582
Dimensions of the product (mm) : 45 x 582 x 520
Dimensions of the packed product (HxWxD) (mm) :
141 x 651 x 578
Net weight (kg) : 10.0
Gross weight (kg) : 11.0
Residual heat indicator : without
Location of control panel : Hob front
Basic surface material : Stainless steel
Color of surface : Stainless steel
Color of frame : Stainless steel
Approval certificates : CE
Length electrical supply cord (cm) : 100
Knob Material : Plastic
Sealed Burners : No
Type of pan support : Elongated cast iron pan support
Electrical connection rating (W) : 1
Gas connection rating (W) : 7500
Current (A) : 3
Voltage (V) : 220-240
Frequency (Hz) : 60; 50
Main colour of product : Stainless steel
Energy input : Gas
Gas type : Liquidgas G30,31 28-30/37 mbar
Alternative gas type : Nat gas H/E/(L) 20 (25) mbar
Approval certificates : CE
Plug type : no plug
Required cutout/niche size for installation (in) : x x
Appliance Dimensions (h x w x d) (in) : + x x
Dimensions of the packed product (in) : 5.55 x 22.75 x 25.62
Net weight (lbs) : 21
Gross weight (lbs) : 23
Total number of positions that can be used at the same time : 4
Length electrical supply cord (cm) : 100
Required niche size for installation (HxWxD) :
45 x 560-562 x 480-492
Dimensions of the product (mm) : 45 x 582 x 520
Dimensions of the packed product (HxWxD) (mm) :
141 x 651 x 578
Net weight (kg) : 10.0
Gross weight (kg) : 11.0
