Design
● ceramic glass surface, black
● Facette fro+rear,side profiles, aluminium, brushed
● cast iron pan support
● BSH flat burner: elegant burner design with less pieces
Comfort & Convenience
● Step valve 9 steps: precisely adjust the flame in nine defined and
repeatable levels.
● yes: clean without effort in the dishwasher.
● Sword Knobs: easily access knobs in front with strong grip for
effortless turning.
● Ignition via control dials: just push and turn the knob to ignite the
flame.
Burners and power
● 5 PC
● Right rear: High speed burner up to 2.8 KW (depending on gas
type)
● Right front: Standard burner up to 1.9 KW (depending on gas type)
Safety
● Flame failure safety device: prevents unwanted gas flow when
flame goes out.
Installation (gas types & measurements)
● Usable for: NG H/E 20mbar, E+ 20/25mbar
● Liquid gas G30,31 28-30/37mbar
● Preset of liquid gas (28-30/37mbar)
● Nozzle set for Natural gas nozzles (20 mbar) included. Nozzles for
all other gas types can be ordered via the customer service. For
nozzle change, please contact the customer service.
● Required niche size for installation (HxWxD mm) : 45 x 850 x (490
– 502)
● Min. worktop thickness: 30 mm
● Dimensions of the product (HxWxD mm): 59 x 912 x 520
● ER9A6SB70Z
● Gas hob, autarkic, 90 cm
● Connected load: 13.8 KW
● Power cord: 1 m
